| Pallet dimensions (length x width) | 1300x1050x2360mm |
| Minum height palletized load | 300 mm |
| Maximum height palletized load | 2400 mm |
| Maximum weight palletized load | 1000 kg |
| Stretch perimeter | 5560-5960mm |
| Transport direction | The long side is parallel to the conveyor, and the short side is perpendicular to the direction of the goods' movement |
| Feeding pallet requirements | Before the product is transported to the packaging station, the pallet centering accuracy should reach ± 10mm; |
| The distance | between the outer contour of the product palletizing type and the longitudinal and transverse centerline of the pallet is ± 10mm. |
| Machine capacity | 60 Pallets/h |
| Kind of consumable material: | Stretch hood |
| Maximum film thickness | 150 my |
| Minimum film thickness | 80my |
| Conveyor line speed | 14m/min |
| Conveyor line height | 600mm |
| Standard voltage | 380 V 3F Neutral |
| Auxilisaries voltage | 24V |
| Allowed voltage variation | % +/-10 |
| Net frequency | 60 Hz |
| Protections: | Ground |
| Motors protections | IP 54 |
| Insulation class for motors: | F |
| Laws | CE 2006/42 and following modifications |
| Compressed air: | 6 Bar |
| Compressed air consumption | Machine 200 NL for hood |
| Environment temperature ranges for equipment running | +0°C - +40°C |
| Environment moisture ranges for equipment running | Max 80% |
| Electrical power installed | 18.5 kw |
