Home > Semi-automatic shrink sealer > FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
1 / 5
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine
FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine

FM5540 FM5540 2-in-1 Heat Shrink Film Packaging Machine,plastic Shrink Wrap Machine

Send Inquiry

Product Description

Why Choose Us
Product Description
Product Description
Model FM5540 FM7060
Type 2 In 1 Shrink Packaging Machine 2 In 1 Shrink Packaging Machine
Power supply 110V,220-240V/50-60HZ 110V,220-240V/50-60HZ
Power 4.0KW 4.0KW
Max. Packing size 550*400*300mm 700*600*300mm
Max. sealing size 550*400mm 700*600mm
Working efficiency 500-800pcs/h 500-800pcs/h
Machine size 1360*670*1080mm 1510*870*1080mm
Machine weight 125KG/145KG 145KG/165KG
Product Detail
Product Detail View 1
Product Detail View 2
Product Detail View 3
Production Facility Overview
Production Facility
Certificate
Certificate Presentation
Exhibiton
Exhibition Gallery
Frequently Asked Questions
What is a 2-in-1 shrink packaging machine?
A 2-in-1 shrink packaging machine integrates both the sealing of the film and the heat-shrinking process into a single chamber. This efficient design allows the machine to seal and shrink the product simultaneously, saving space and operating costs.
What are the main differences between the FM5540 and FM7060 models?
The primary difference is their capacity. The FM5540 has a maximum packing size of 550*400*300mm with a sealing size of 550*400mm, whereas the FM7060 is designed for larger objects, offering a maximum packing size of 700*600*300mm and a sealing size of 700*600mm.
Can these machines support different voltage requirements?
Yes, both the FM5540 and FM7060 models are highly adaptable. They can be configured to support power supplies of 110V or 220-240V at 50-60HZ, making them compatible with various industrial power grids worldwide.
What is the average working efficiency of the FM series?
Both models can pack between 500 to 800 pieces per hour. The actual output depends on the operator's speed, the material thickness, and the dimensions of the items being packaged.
Are these machines easy to transport and set up?
Yes, the machines are mounted on wheels for easy mobility within your production facility. The FM5540 weighs 125KG to 145KG, and the FM7060 weighs 145KG to 165KG, providing a highly stable platform that is easy to position.
