Note: With foot stand, adjustable height of workbench Girth 550-780mm ± 50mm
Equipment Configuration & Construction
Frequently Asked Questions
Q
Which shrink films are compatible with the BF450 Side Sealer and BSN4020C Shrink Tunnel?
The BF450 Side Sealer is designed to process POF and PE shrink films. The BSN4020C Shrink Tunnel is compatible with POF and PVC shrink films.
Q
What is the packaging speed capability of the BF450 Side Sealer?
The BF450 Side Sealer offers an operating speed of 15 to 30 bags per minute, depending on the product dimension and film properties.
Q
What are the dimensions limitations for packaging products?
For the BF450 Side Sealer, the length (L) is unlimited, the height (H) must be ≤ 150mm, and the combined width and height (W+H) must be ≤ 300mm. For the BSN4020C Shrink Tunnel, the maximum product size is 200 * 100mm.
Q
What type of conveyor configurations are available for the BSN4020C Shrink Tunnel?
The BSN4020C can be customized with various conveying materials including Chain roller, Net Belt, Teflon, and Chain net to suit different packaging requirements.
Q
What are the electrical and air pressure requirements for these machines?
The BF450 Side Sealer requires 220V/50-60HZ voltage, 1.1KW power, and 6.0-8.0kgf/cm² (0.6-0.8MPa) air pressure. The BSN4020C Shrink Tunnel operates on 220V-380V/50-60HZ with 9KW power.
Q
Can the height of the workbench be adjusted?
Yes, the BSN4020C Shrink Tunnel is equipped with a foot stand that enables an adjustable workbench height with a girth of 550-780mm ±50mm.
